On-Stage DB500 Passive DI Box
On-Stage DB500 Passive DI Box
SKU:XOSDB500
Couldn't load pickup availability
The DB500 Direct Box transforms any high-impedance 1/4" source into a low-impedance (XLR) signal ready to be sent long distances to a mixing board or recording console. Its passive design features a high quality transformer, ground lift switch, and does not require batteries or phantom power. Perfect for bass/acoustic guitar, keyboards, and DJ equipment.
 Â- Transforms any high-impedance 1/4" source into a low-impedance (XLR) signal ready to be sent long distances to a mixing board or recording console
- Passive design features a high quality transformer, ground lift switch, and does not require batteries or phantom power
- Perfect for bass/acoustic guitar, keyboards, and DJ equipment
- Ground lift switch
Â
Tech Specs
Â
Inputs:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 1/4"
Output:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â XLR
Power:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Passive/not required
Pad:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 20dB, 40dB, Ground Lift: Yes
Input Impedence:Â Â Â Â Â Â Â Â 350K Ohms
Output Impedence:Â Â Â Â Â 80 Ohms
Construction:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Metal
Dimensions:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â (W)4.75" x (H)1.375" x (D)2.875"
Weight:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 0.5 lbs.
